I. Energy Storage System Parameters

• Rated Power: 50kW

• Nominal Capacity: 100kWh

• Battery Voltage: 500V

• Charge/Discharge Rate: ≤0.5C

• Depth of Discharge (DOD): ≤95% (Recommended)

• Cycle Life: >6000 cycles

• Cell Type: Lithium Iron Phosphate (e.g., 3.2V/173Ah, 3.2V/280Ah)

• Energy Storage System Efficiency: ≥90%

II. Charging Facility Parameters

• Output Power: 40kW - 50kW

• Input Voltage: AC380V±15%

• Output Voltage Range: DC200V - 500V

• Output Current Range: 0 - 200A

III. PV Parameters

• Rated Power: 50kW

• Voltage Range: DC300V - 500V

• Current Range: 0 - 300A
